- Finish
- White
60cm 300 Series
Telescopic Wall Rangehood
- 2 fan speeds
- Maximum decibel rating - 66dBA
Height
180mm
Width
598mm
Depth
280 - 460mm
Specifications
- Height
- 180mm
- Width
- 598mm
- Depth
- 280 - 460mm
Accessories (included)
Accessories (included) Attributes | Value |
---|---|
Aluminium filter | 792391 |
Eave ducting kit | PD-RHK125E |
Light bulb | 791822 |
Recirculation carbon filter | 792390 |
Roof ducting kit | PD-RHK125T |
Side wall ducting kit | PD-RHK125W |
Fan ratings
Fan ratings Attributes | Value |
---|---|
Maximum air movement | 340m³/hr |
Maximum sound rating | 66dBA |
Installation and cleaning
Installation and cleaning Attributes | Value |
---|---|
Air outlet size | 120mm |
Dishwasher safe filters | 2 |
Ducted | Top extraction only |
Recirculation | No |
Performance
Performance Attributes | Value |
---|---|
Extraction type | Surface |
Fan speeds | 2 |
Filter type | Mesh |
Number of filters | 2 |
Power requirements
Power requirements Attributes | Value |
---|---|
Supply frequency | 50Hz |
Supply voltage | 220 - 240V |
Product dimensions
Product dimensions Attributes | Value |
---|---|
Depth | 280 - 460mm |
Height | 180mm |
Width | 598mm |
Product information
Product information Attributes | Value |
---|---|
Control type | Switch |
Ventilation features
Ventilation features Attributes | Value |
---|---|
Light type | LED 2 x 3.5W |
Warranty
Warranty Attributes | Value |
---|---|
Parts and labour | 2 years |
Resources
Please note: Videos are not for downloading purposes
Download the resource
Download and open pdf in new tab
General
- Quick Reference guide
-
60cm 300 Series Telescopic Wall Rangehood, GeneralFiles-HaierNZ
User Guide
