HC60PLX4
Wall Rangehood, 60cm, Pyramid Chimney
With powerful extraction, this rangehood effectively captures and eliminates cooking odours, vapour and steam. It is the perfect partner to our cooktops, featuring a low profile and finished with sleek brushed stainless steel.
Stainless Steel
| Finish | Stainless Steel |
|---|
Wall Rangehood, 60cm, Pyramid Chimney
- 3 fan speeds
- Optional recirculated ducting
- Maximum decibel ratings - 65dBA
Height
610 - 1050mm
Width
598mm
Depth
500mm
Specifications
- Height
- 610 - 1050mm
- Width
- 598mm
- Depth
- 500mm
Accessories
| Aluminium filter | 792527 |
|---|---|
| Chimney extension | 792492 (Cover duct extension 850mm) |
| Eave ducting kit | PD-RHK15OE |
| Light bulb | 792461 |
| Recirculation carbon filter | 792481 |
| Roof ducting kit | PD-RHK15OR |
| Side wall ducting kit | PD-RHK15OW |
Fan ratings
| Maximum air movement | 780m³/hr |
|---|---|
| Maximum sound rating | 65dBA |
Installation and cleaning
| Air outlet size | 120 - 150mm |
|---|---|
| Dishwasher safe filters | 2 |
| Ducted | Top extraction |
| Recirculation | Optional - top extraction |
| Two piece height adjustable flue |
Performance
| Extraction type | Surface |
|---|---|
| Fan speeds | 3 |
| Filter type | Mesh |
| Number of filters | 2 |
Power requirements
| Supply frequency | 50Hz |
|---|---|
| Supply voltage | 220 - 240V |
Product dimensions
| Depth | 500mm |
|---|---|
| Height | 610 - 1050mm |
| Width | 598mm |
Product information
| Control type | Push Button |
|---|
Ventilation features
| Light type | LED 2 x 3.5W |
|---|
Warranty
| Parts and labour | 2 years |
|---|
Resources
General
- Quick Reference guide
-
User Guide
Wall Rangehood, 60cm, Pyramid Chimney, GeneralFiles-HaierNZ
